SMP858-TSF-D Gauge Pressure Transmitter

---

Key features

• Pressure type: gauge pressure
• Measuring range: 10kPa-3MPa
• Output signal: 4-20mA, 4-20mA+HART
• Reference accuracy: ±0.2% URL, ±0.5% URL

---

About The SMP858-TSF-D Gauge Pressure Transmitter

Hygienic pressure transmitter, designed for food
and pharmaceutical industry, is suitable for
CIP/SIP cleaning and sterilization. Smart compact
design, the welded process diaphragm medium
parts is made of high quality stainless steel 316L,
roughness≤0.4um, filling fluid with hygiene
standard in line with FDA certification, variety of
international standard process connections are
available.

Environmental conditions

• Working temperature -40-85°C, integrated LCD display:-20-70°C
• Storage temperature -40-110°C, integrated LCD
  display: -40-85°C
• Media temperature Hygienic fluid filling: -10-125°C
• Silicon oil filling: -40-120°C
• Working humidity 0-95%RH
• Protection class IP67

Application

• Pharmacy
• Food
•  Beverage

---
