AWMD-5 Full Bridge Strain Gauges for Dynamic Measurement
This 5mm gauge is applicable up to 800°C and dedicated to dynamic measurement
Do you need this sensor for your next project?
Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.
Product downloads
Talk to our experts
Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.
Talk to an expertTechnical Specifications
| Specification | Value |
|---|---|
| Backing | Inconel |
| Bonding adhesive | Spot welding (TML spot welder W-50R is required) |
| Element | Special alloy |
| Fatigue life at room temperature | 1×10⁶ (±1000×10⁻⁶ strain) |
| Main object material | Metal |
| Operational temperature(°c) | -196~+800°C |
| Strain limit | 1% (10000×10⁻⁶ strain) |
| Temperature compensation range(°c) | - |
