eDXI-100/200 Single or Dual Axis Digital Inclinometer
1-Axis or 2-Axis Inclinometer with Ethernet Output.
Key features
- Digital output
- Resolution 0.001°
- Mechanical Shock 1500g 1msec 1/2 sine
- Industry Standard Ethernet 10 Base T or 100 Base TX (Auto-sensing)
- For use in high shock and vibration environments
- PoE (power over Ethernet)
- Low Noise
About the eDXI-100/200 Servo-Inclinometer
Digital 1- or 2-Axis Servo Inclinometer with Ethernet (PoE)
The Jewell eDXI-100/200 is a high-precision digital inclinometer available in 1-axis or 2-axis configurations, featuring convenient Ethernet connectivity.
With integrated Power over Ethernet (PoE) capability, no separate power supply is required. A single Ethernet cable provides both power and data transmission — simply connect the sensor directly to your computer or network infrastructure for immediate integration.
Key Features
- 1-axis or 2-axis configurations available
- Digital Ethernet output
- Power over Ethernet (PoE) — no external power supply required
- High-accuracy servo technology
- Stable and reliable digital signal transmission
- Designed for industrial and safety-critical environments
- RoHS-certified version available upon request
Why Choose Ethernet & PoE?
The Ethernet interface offers major advantages for modern control and monitoring systems:
- Direct integration into existing network architectures
- Simplified wiring and installation
- Reduced system complexity
- Lower susceptibility to electrical noise
- Enables remote monitoring and centralized data acquisition
PoE eliminates the need for additional power supplies, making it ideal for distributed measurement systems and retrofit installations.
Typical Applications
The eDXI-100/200 is widely used in:
- Radar and antenna control
- Structural monitoring
- Linear acceleration and deceleration measurement
- Automatic Train Control (ATC, ATP)
It is particularly suited for applications requiring high-precision tilt measurement combined with digital network communication.
Do you need this sensor for your next project?
Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.
Product downloads
Talk to our experts
Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.
Talk to an expertTechnical Specifications
| Specification | Value |
|---|---|
| 0° output temp. sensitivity (°/°c, max) | 0.005 |
| Bandwidth (-3db hz, nominal) 3 | 3, 6, 30, 30, 30 |
| Hysteresis (° max) | 0.001 |
| Input current (ma, max) | 250 |
| Input range (°) | ±1.0, ±3.0, ±14.5, ±30.0, ±60.0 |
| Input to output isolation (vpeak impulse) | 1500 |
| Noise (milli-degrees rms, max) | 2 |
| Non linearity (%fro max)2 | ±1.0 / 0.02, ±3.0 / 0.015, ±14.5 / 0.02, ±30.0 / 0.02, ±60.0 / 0.03 |
| Number of axes | 1 or 2 |
| Operating tem p. range | -40° to +85°C |
| Output at 0° tilt (max) | ±0.01, ±0.01, ±0.05, ±0.05, ±0.05 |
| Power on repeatability (° max) | 0.001 |
| Resolution & threshold (° max) | 0.001 |
| Scale factor temp. sensitivity (ppm/°c, max) | 100 |
| Scale factor tolerance (% max) | 0.1 |
| Shock | 1500g, 1 msec, ½ sine |
| Start-up voltage (vdc, min) | 42 |
| Storage temp . range | -40° to +85°C |
| Supply voltage range (vdc) | 36 to 57 |
| Vibration | 20 grms |
