P101 Stand-alone linear inductive position sensor

Robust, compact sensor for precise position feedback in industrial and scientific environments. Flexible installation and fully customizable stroke length up to 800 mm.


Key features

  • Contactless inductive technology for long life and no wear
  • Stainless steel housing and push rod for high durability
  • Customizable measurement stroke from 5 mm to 800 mm
  • Available with axial or radial cable/connector options
  • Compatible with multiple signal outputs (0.5–10 V, 4–20 mA)
  • Sealing up to IP65/IP67 for harsh environments

About the P101 Linear Inductive Position Sensor

Versatile linear feedback for industrial use. The P101 from Althen is a self-contained linear position sensor delivering high-resolution stroke feedback. Its compact form factor and flexible configurations make it ideal for industrial machinery, automation systems, and OEM product integration.

Further features

  • Non-contact inductive measurement for long service life
  • Custom-calibrated travel from 5 mm to 800 mm
  • Multiple mounting options: rod eye, dome end, magnetic tip
  • Wide output options including voltage and 4–20 mA current loop
  • Compatible with body clamps and sprung push rod up to 300 mm

Reliable, wear-free technology

Utilizing non-contact inductive sensing with ASIC control, the P101 provides absolute position feedback with zero mechanical wear, infinite resolution, and outstanding repeatability. The system is resistant to vibration, shock (40g), and pressure up to 350 bar, making it suitable for harsh environments.

Custom travel lengths & output types

Each unit is factory calibrated to a travel length between 5 mm and 800 mm. Supported output types include:

  • 0.5–4.5V ratiometric
  • ±5V / ±10V
  • 0.5–9.5V
  • 4–20 mA (2 or 3 wire)
    The P101 is EMC-compliant (EN 61000-6-2 & -6-3) and sealed to IP65 or IP67, depending on cable/connector choice.

Flexible mounting & rod configuration

The P101 can be mounted using M5 rod eye bearings, clamps (codes P/P2), or directly threaded. Push rod options include free or captive, sprung-loaded (up to 300 mm), with female M5 thread, rod-eye, dome end, or magnetic tip. Full installation and pinout details are shown on pages 3–5.

Applications

  • Linear displacement in test benches and automation
  • Control feedback in industrial equipment
  • Scientific instrumentation
  • OEM actuators and mechatronic systems

Do you need this sensor for your next project?

Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.

Talk to an expert

Talk to our experts

Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.

Talk to an expert

Technical Specifications

Specification Value
Stroke range 5 mm to 800 mm (custom)
Linearity ±0.25% FSO to 450 mm, ±0.5% beyond
Sealing IP65 or IP67
Resolution Infinite
Operating temperature -40 °C to +125 °C
Output signals 0.5–4.5V, ±5V, ±10V, 0.5–9.5V, 4–20 mA
Frequency response >10 kHz (voltage), >300 Hz (current)
Vibration resistance 10 g (IEC 68-2-6)
Shock resistance 40 g (IEC 68-2-29)
Sealing IP65 or IP67
Body and rod material Stainless steel
Rod fittings M5 thread, dome, magnetic, rod eye
